12.1" F121PET-T52 LCD Module with Touch (PCAP)

LCD Panel
Resolution:12.1" 1280 x 800 (WXGA)
White Luminance(w/ touch):≧425 (typ)cd/㎡
Viewing Angle:≧89/89/89/89
LED Life Time(Hrs):≧70,000
Interface:LVDS

Operating Temp.(℃):-20~70
Touch
Touch Type:PCAP
Bonding Type:Air Bonding
Structure:G/G
Touch IC:EETI
Transparency:≧85%
Surface Hardness:≧6H
FPC Type:COF
Touch Interface:USB. I2C
Allow Touch Points:10 points
Specifications
Wide View Angle
Lamp > 70K Hours
